SOB Strip
SOB High density led strip 400LEDs/M 24V 8mm SMD LED with supporting substrate
MR-CM2025240804S （400LEDs/M）
* High-density LED array
* Within 3-step SDCM
* SMD LED with supporting substrate
* Adopting small-size lamp beads as light source, high-density of lamp beads, no dark area of light emitting
* IP Rating IP20
* Ambient Temperature: -4°F to 104°F (-20°C to 40°C)
* Lamp Life : 50,000 Hours
Product Certification
Product Parameters
Product | Input Voltage | Power | LED Type | PCB width | LED Qty | Cuttable Size | CCT | Lumen/M | CRI | Beam Angle | IP Rating | Length per roll |
MR-CM2025240804S | 24V | 10W/M | SMD 2025 | 8mm | 400LEDs/M | 8LED, | 3000K | 800lm/m | Ra＞90 | 120° | IP20 | 10M/Roll |
4000K | 850 lm/m | |||||||||||
6000K | 912 lm/m |
